HEGERLS Long Span Racking System
HEGERLS Long Span Racking System
HEGERLS Long Span Racking System
HEGERLS Long Span Racking System
HEGERLS Long Span Racking System
HEGERLS Long Span Racking System
HEGERLS Long Span Racking System
HEGERLS Long Span Racking System

HEGERLS Long Span Racking System

Flexible Medium Duty Storage Solution for Manual Picking and Multi-Purpose Warehouses

HEGERLS Long Span Racking System is a versatile warehouse shelving solution designed for medium-sized goods storage, manual picking operations, and industrial warehouse organization.



Also known as medium duty shelving or wide span racking, the system combines upright frames, beams, and shelf panels to provide stable storage performance with flexible configuration.



With adjustable shelf levels, strong load capacity, and multiple decking options, HEGERLS Long Span Racking is widely used in warehouses, spare parts centers, workshops, retail storage areas, and logistics facilities.

Inquire Now Next Product

System Composition

Core Competitive Advantages

Technical Specifications

Working Principle & Process

Industry Solutions

System Composition

HEGERLS Long Span Racking System adopts a modular assembled structure consisting of upright frames, horizontal beams, and shelf panels.

The components are connected through plug-in and boltless structures, allowing quick installation, easy adjustment, and flexible warehouse layout changes.

Different shelf materials, including steel panels, galvanized sheets, wooden boards, and wire mesh decking, can be selected according to storage requirements.

Main Components:

Upright Frames

Horizontal Beams

Shelf Panels

Side Supports

Back Bracing

Cross Bracing

Floor Anchoring Components

Safety Accessories

Core Competitive Advantages

1
Flexible Storage Configuration

The adjustable beam structure allows shelf levels to be adjusted with approximately 50 mm pitch, enabling efficient storage of goods with different heights and sizes.

2
Medium Duty Load Capacity

HEGERLS Long Span Racking provides reliable storage performance for various manual handling applications.

Typical load ranges:

Light Duty: 100–150 kg per level

Medium Duty: 150–300 kg per level

Customized designs are available for higher load requirements.

3
Strong & Stable Structure

The optimized upright and beam design improves overall stability through:

Side frame support

Horizontal bracing

Back reinforcement

Secure beam-column connection

Ensuring safe and reliable long-term operation.

4
Easy Installation & Expansion

The fully assembled structure allows fast installation, dismantling, and relocation.

The modular design enables warehouses to expand storage capacity easily according to future requirements.

5
Multiple Shelf Options

HEGERLS provides different shelf configurations:

Steel Panels

Galvanized Panels

Wooden Boards

Multi-Layer Boards

Wire Mesh Decking

Meeting different storage environments and application needs.

6
Cost-Effective Storage Solution

With simple structure, convenient installation, and economical investment, Long Span Racking provides an ideal storage solution for warehouses requiring flexible manual storage.

Technical Specifications

Parameter

Specification

Product Type

Long Span Racking System

Alternative Name

Medium Duty Shelving / Wide Span Shelving

Application

Manual Picking & Storage

Structure

Upright Frame + Beam + Shelf Panel

Light Duty Capacity

100–150 kg / Level

Medium Duty Capacity

150–300 kg / Level

Beam Adjustment

Approx. 50 mm Pitch

Shelf Material

Steel Panel / Wood Board / Wire Mesh

Installation Method

Boltless Assembly

Surface Treatment

Electrostatic Powder Coating

Configuration

Customized

Working Principle & Process

  • 01
    Goods Receiving

    Products are delivered to the storage area and classified according to size, weight, and storage requirements.

  • 02
    Shelf Position Planning

    Storage levels are adjusted according to product dimensions to maximize available space.

  • 03
    Manual Storage Operation

    Operators place goods directly onto shelf panels for organized storage.

  • 04
    Picking & Inventory Management

    Products can be accessed directly from each shelf level, improving picking efficiency and inventory visibility.

HEGERLS Long Span Racking System
Long Span Racking Configuration Options

Light Duty Long Span Racking

Designed for lightweight goods storage with load capacity typically ranging from 100–150 kg per level.

Suitable for small parts, tools, and retail storage.

Medium Duty Long Span Racking

Designed for heavier manual storage applications with load capacity typically ranging from 150–300 kg per level.

Suitable for industrial warehouses and spare parts storage.

Customized Long Span Shelving

HEGERLS can customize:

Rack height

Rack length

Shelf depth

Load capacity

Decking materials

According to customer requirements.

Logistics System Connection

Goods continue to the next process:

Storage

Sorting

Picking

Production

Shipping

Related Products
HEGERLS Clad Rack Warehouse
HEGERLS Clad Rack Warehouse
Integrated Rack-Supported Warehouse Solution for High-Bay Automated Storage
HEGERLS High Bay ASRS Racking
HEGERLS High Bay ASRS Racking
Automated High-Bay Storage Rack System for Intelligent Warehouse Automation
HEGERLS Supermarket Shelving System
HEGERLS Supermarket Shelving System
Flexible Retail Display Shelving Solution for Supermarkets & Commercial Stores
HEGERLS Steel Platform System
HEGERLS Steel Platform System
Heavy-Duty Steel Structure Platform for Maximizing Industrial Space Utilization

FAQ

Q1. What is Long Span Racking?

Long Span Racking is a medium-duty shelving system designed for storing medium-sized goods, cartons, spare parts, and manually handled products.

Q2. What is the load capacity of Long Span Racking?

HEGERLS Long Span Racking typically supports 100–300 kg per shelf level depending on the structure and configuration.

Q3. What is the difference between Long Span Racking and Pallet Racking?

Long Span Racking is designed for manual picking and smaller goods storage, while pallet racking is designed for palletized goods handled by forklifts.

Q4. Can Long Span Racking be customized?

Yes. HEGERLS provides customized solutions according to warehouse dimensions, product sizes, load requirements, and operational needs.

Q5. Is Long Span Racking easy to install?

Yes. The modular assembled structure allows quick installation, adjustment, expansion, and relocation.
